Vertical sealing and cutting shrinking machine PC-600LV+PS-4525

The function introduction of the sealing, cutting and shrinking machine is to automatically wrap the shrink film on the outside of the package, then heat the packaging material to shrink and wrap the product tightly, and use photoelectric to automatically detect the product to realize automatic unmanned packaging. It has high work efficiency and is suitable for packaging products of different sizes and switches. It is widely used in food, medicine, aluminum profile, water pipe, printing, photo frame, electronics, daily chemicals, cosmetics and other mass production industries. It plays a role in moisture-proof, pollution prevention and avoiding certain external impact. Cost saving is the way to improve competitiveness. It is a difficult problem to effectively save costs and maintain quality. Gh-600lv can achieve the purpose of improving cost-effectiveness. It has continuous sealing action, so that its packaging speed can reach 1-50 bags per minute. The design of fully automatic operation and high-efficiency packaging can save manpower. It is equipped with high-speed cylinder control system and finger push conveying system, so that the machine can still maintain stability under high-speed operation, and the side sealing device can reduce the generation of residual film, Effectively reduce material costs. According to different products, different simple and multi-functional product conveying systems are configured to automate the production line and save workers' costs. With the help of different conveying systems, the machinery can be easily integrated with the production line to meet different needs.

1) Siemens programmable controller is adopted to realize the computer Electricity Gas integration

2) Photoelectric switch automatically detects that the product is in place

3) Use imported spare parts to ensure the stability of the machine at high speed;

4) The height of the sealing line can adapt to the automatic adjustment of the height of the package

5) The L-shaped cutter is driven by the vertical system to ensure that the sealing line is straight and firm;

6) It has a wide range of packaging and can package products of various sizes and shapes;

7) Packaging capacity, up to 1-50 pieces per minute

8) The cutter can select automatic upper and lower cutting and sealing height, and the control system can be switched

9) The specially designed V-shaped sealing knife is adopted, the sealing line is firm and does not split, the external part of the knife body is plated with high temperature resistant Teflon, there is no mucous membrane, the knife does not stick, the sealing has no peculiar smell, and the servo cutter controls the sealing up and down to cut off more accurately

10) The limit switch sends film, which greatly reduces the loss of film

11) The film feeding device is driven by the synchronous belt, and the operation is more stable and accurate without noise

12) The original Omron digital display temperature controller imported from Japan has accurate temperature and can directly see the sealing, cutting and shrinkage temperature

13) The transmission adopts the reduction motor to control the front and rear transmission speed, and the transmission of the brake controller is more stable

14) The super large air volume cools the air flow, and the product cools rapidly after thermal expansion, shrinks and sets

15) The machine adopts stainless steel 304 heating tube for heating

16) The constant temperature circulating air duct system makes the temperature in the shrinkage bin more uniform and makes the shrinkage products achieve good results

17) The solid wire drawing steel rod is wrapped with imported silicone hose, and the chain rod conveying is durable. The conveying structure of different materials can be adopted according to different products

18) The shrink film is placed in the lower half of the machine to facilitate the replacement of the shrink film and prevent employees from injury due to strain when replacing the shrink film

19) Portable punching device, flexible adjustment and convenient replacement. Imported fiber roller replaces rubber roller, which is durable

20) Different product conveying devices can be configured to form a full-automatic production line suitable for customers

21) the film charging system can reduce the number of remaining films and save the packaging cost for customers. Compared with other machines, it can save 2% to 5% of the material cost

22) the touch screen control system is easy to operate and reduces unnecessary human errors

O the display screen automatically displays errors, which is convenient for operators to correct operation errors

O machinery is adjusted by numerical value, which makes it faster and easier to change products or production speed

O product memory function, which can remember the numerical data of 100 products and provide time-saving and fast product replacement

23) packaging: totally enclosed packaging (paint baking color and rack material are optional)

24) use environmental friendly POF shrink film 1.2-3.8 silk as the packaging material (radiation changing molecular cross-linked film can also be used in the market)

25) supporting equipment

Full automatic multifunctional blanking device, suitable for single close product

The vertical blanking device can be used with finger push conveyor belt and translation belt

5） Equipment configuration table: model pc-600lv
